VD-Back Pressure Vacuum Puffing Machine
| Model | PHJ-600-2 | PHJ-1200-2 | PHJ-1200-4 |
| Parameter | |||
| Material | Food grade 304 stainless steel | Food grade 304 stainless steel | Food grade 304 stainless steel |
| Vacuum pot size | 3600*1000mm（Diameter） | 5500*1800mm（Diameter） | 10000*1800mm（Diameter） |
| Vacuum pot plate thickness | 8mm | 8mm | 8mm |
| Flash evaporation pot size | 1650*600mm（Diameter） | 2800*1200mm（Diameter） | 2800*1200mm（Diameter） |
| Flash evaporation pot thickness | 6mm | 6mm | 6mm |
| Heating mode | Steam | Steam | Steam |
| Steam consumption | 60kg/h | 160kg/h | 320kg/h |
| Flash evaporation pot door open mode | Manually | Manually | Manually |
| Capacity | 3kg/ pot for material
Total 6kg/batch |
40kg/ pot for material
Total 80kg/batch |
40kg/ pot for material
Total 160kg/batch |
| Processing time | According to the products | According to the products | According to the products |
| Vacuum pot cooling mode | Water cooling | Water cooling | Water cooling |
| Thermal insulation material | Rock wool | Rock wool | Rock wool |
| Thickness of insulation layer | 50mm | 50mm | 50mm |
| Vacuum pump power | 14kw/set 1set | 19kw/set 1set | 19kw/set 2set |
